Profender 12-Inch Triple Bypass Shock Kit
IMPORTANT: I have slightly re designed this mount so it may vary from the pictures, will add updated pictures soon
Mount Compatibility: Designed for a 1.75-inch mount width with a 5/8-inch hole
Lift & Components: There are 4 models to choose from
Option 1: Suitable for 12 inch shock for vehicles with a 1-2 inch lift, tower sits roughly 280mm above the coil hat, has a 25mm raised bump stop pad to get the bump spacing correct.
Option 2: Lower profile version Suitable for 12 inch shock for vehicles with a 3-4 inch lift, tower sits roughly 200mm above the coil hat, has a 50mm raised bump stop pad to get the bump spacing correct.
Option 3: Suitable for 14 inch shock for vehicles with a 3-4 inch lift, This uses the upper mount of the 1-2 inch kit and the lower mount of the low profile 3-4 inch kit to allow for the extra room needed to suit the 14 inch shock. Tower sits roughly 280mm above the coil hat, has a 50mm raised bump stop pad to get the bump spacing correct.
Option 4: Suitable for 12 inch shock for vehicles with a 2-4 inch lift but sits perfect at 3 inch, these are mounted to the front side of the rear diff to help package the suspension better without fouling on the panhard. This also means you can run a raised panhard bracket to help the panhard operate in a more ideal part of the arc and also raise the roll centre. Tower sits roughly 220mm above the coil hat, has a 30mm raised bump stop pad to get the bump spacing correct.
Complete Kit: Comes as a complete flat pack ready to assemble and weld together, you are required to drill out any necessary holes, slight clearancing may be required on the chassis end Panhard mount to stop the bypass tube fouling at full bump and a slight notch on the passenger side rail for the bypass tube on the rear mounted kits
There is an option to add the coil hat brace if needed, if you already have a brace then please select No.
Built for off-road use only.
Components: Made from 5mm GR350 steel
Comes as a flat pack with upper and lower mounts, remote res/centre brace mounts and bump stop pads included.
Length -
Width -
Hight -
Shipping & Returns Policy
Shipping
We aim to process and dispatch all orders within two to three weeks depending on stock levels. Shipping times vary depending on your location and chosen shipping method. Once your order is shipped, you will receive a tracking number to monitor its progress.
Please note that delivery times may be affected by holidays, weather conditions, or carrier delays beyond our control.
